Technology
Hybrid steering:
more performance from less power.
Electronic steering in elevation, mechanical in azimuth.
- Power
- >12 W for LEO
- Polarisation
- Switchable RHCP and LHCP
- Data Rate
- 800 Mbps
>36 W for GEO
Without polariser
Downlink
How it works
Electronic steering in elevation,
mechanical in azimuth.
Most flat-panel antennas steer their beam using around a thousand electronic components, which makes them costly, power-hungry, and prone to heat-related issues. NECT steers electronically in elevation and mechanically rotates in azimuth, drawing less power and delivering higher RF performance.
- Array
- Ku- and Ka-band hybrid phased array
- Elevation
- Electronic, −60° to +60°
- Azimuth
- Mechanical, ±180°, < 300 ms
- Aperture
- Single TX/RX
- Polarisation
- RHCP/LHCP switchable
- Gain (Ku)
- ≥ 33 dBi
- EIRP (Ku)
- Up to 50 dBW
- G/T
- 15 dB/K @ broadside,≥ 13.5 dB/K over the scanning range
Drone version · 20 × 8 × 1.5 cm
